CapillaryScope 500 Pro Wireless

CapillaryScope 500 Pro Wireless

The Dino-Lite CapillaryScope 500 Pro Wireless (MEDLW4N5 PRO) is the next generation of CapillaryScope offering both wired and wireless operation out of the box. Adjustable polarisation and removable end caps further add to the flexibility offered by this model.

  • USB and Wi-Fi Capable
  • 1.3 Megapixel Resolution
  • Exchangeable Contoured End Caps
  • 500x Magnification
  • Adjustable Polarizer & Flexible LED Control
  • Medical Device Class 1

WirelessUSBMag-500

mag-lockres-1-38-leds

PolariserIexch-cap

The 500x optics of this model have been selected for capillaroscopy applications that require greater detail of individual nail capillaries than can be obtained with the 200 Pro models. When using the contoured nail cap as intended the 500x optics provide the user with a field of view of approximately 0.85mm in the x direction. For more general applications that do not require this greater level of detail the MEDLW4N Pro Wireless is available and offers approximately 1.8mm field of view.

The removable N3C-N caps that clip to the end of the CapillaryScope are contoured to the finger and make hand held operation extremely straightforward. These along with the adjustable polarisation make contact operation (usually with immersion oil) a quick and simply process producing high quality images of the nail capillary formations.

Additional Info

  • Resolution: 1280x1024pixels(1,3MP)
  • Magnification: 500-500x
  • Working Distance: Standard
  • Interface: USB + WiFi
  • Nr. of LED's: 8
  • LED on/off switchable: Yes
  • LED color: White
  • Material: Composite
  • Exchangeable caps: Yes
  • Microtouch: Yes
  • Scroll lock: Yes
  • Output: Picture, Video, Time-lapsed video
  • Video Frame Rate: Up to 30 frames-per-second
  • Measurement: No
  • Calibration: No
  • Filter/Diffuser: Built-in polarizer
  • Compatibility: Windows 10/11, MacOS 10.4 or later
  • Software: DinoCapture for Windows, DinoXcope for MacOS
  • JPEG Codec: None
  • Special:



    Allows USB or Wi-Fi Operation

    Regulatory approval: Medical Device Class 1 – According to Directive 93/42/EEC modified 2007/47/EC
  • Package contents:



    Microscope, Carry pouch, User manual

    End Caps Supplied N3C-N (CapillaryScope specific)
