CapillaryScope 200 Pro Wireless

CapillaryScope 200 Pro Wireless

The Dino-Lite CapillaryScope 200 Pro Wireless (MEDLW4N PRO) is the next generation of CapillaryScope offering both wired and wireless operation out of the box. Adjustable polarisation and removable end caps further add to the flexibility offered by this model.

  • USB and Wi-Fi Capable
  • 1.3 Megapixel Resolution
  • Exchangeable Contoured End Caps
  • 20x-220x Magnification
  • Adjustable Polarizer & Flexible LED Control
  • Medical Device Class 1

WirelessUSBMag-20-220

mag-lockres-1-38-leds

PolariserIexch-cap

The 20x-220x optics of this model have been selected with capillaroscopy applications in mind and when using the contoured nail cap as intended provide the user with a field of view of approximately 1.8mm in the x direction. For applications that require greater detail of individual nail capillaries the MEDLW4N5 Pro Wireless is also available (approximately 0.85mm field of view).

The removable N3C-N caps that clip to the end of the CapillaryScope are contoured to the finger and make hand held operation extremely straightforward. These along with the adjustable polarisation make contact operation (usually with immersion oil) a quick and simply process producing high quality images of the nail capillary formations.

Additional Info

  • Resolution: 1280x1024pixels(1,3MP)
  • Magnification: 20-220x
  • Working Distance: Standard
  • Interface: USB + WiFi
  • Nr. of LED's: 8
  • LED on/off switchable: Yes
  • LED color: White
  • Material: Composite
  • Exchangeable caps: Yes
  • Microtouch: Yes
  • Scroll lock: Yes
  • Output: Picture, Video, Time-lapsed video
  • Video Frame Rate: Up to 30 frames-per-second
  • Measurement: No
  • Calibration: No
  • Filter/Diffuser: Built-in polarizer
  • Compatibility: Windows 10/11, MacOS 10.4 or later
  • Software: DinoCapture for Windows, DinoXcope for MacOS
  • JPEG Codec: None
  • Special:



    Allows USB or Wi-Fi Operation

    Regulatory approval: Medical Device Class 1 – According to Directive 93/42/EEC modified 2007/47/EC
  • Package contents:



    Microscope, Carry pouch, User manual

    End Caps Supplied N3C-N (CapillaryScope specific)
